IGLU® System
Double glazed louvre
The revolutionary Altair® IGLU® Double Glazed Louvre System allows maximum ventilation through the window opening while providing high thermal performance.
The IGLU double glazed louvre is ideal for use in colder climates, or any applications that require higher levels of thermal insulation.
IGLU
Features
Maximum Ventilation
Award Winning
Thermal Insulation
Frameless Glazing
No thermally compromised framing and with blade-to-blade sealing.
Customisable
Strong & Safe
Incorporates the Stronghold System for added strength and safety.
- 90% ventilation as per the NCC Definition of a ventilation opening. Using a more conservative and realistic definition of the ventilation opening, the thicker IGLU blades will reduce the ventilation opening to approximately 80% of the total window area.
- Winner of the 2023 Good Design Award and 2023 AGWA Design Award for ‘Most Innovative Window System’.
- The IGLU System is supplied with black clips. Handles and frames can be colour matched to suit your designs. Please speak to Breezway for more information.
Ventilation
Natural ventilation is important in any home or working environment. It helps keep the air we breathe clean and fresh, preventing mould or moisture build-up whilst maintaining a connection with our outdoor environment. The IGLU Double Glazed Louvre System opens twice as wide as other window types to offer maximum ventilation and capture breezes no matter the wind direction.
Compliant & Safe
The IGLU Double Glazed Louvre incorporates the Stronghold® System to ensure compliance with Fall Prevention requirements. With increased acoustic performance and the low-risk pinch or edge impact hazards due to soft seal-on-seal closure make the IGLU System ideal for education environments.
Energy Performance
The 22mm IGLU Blade, comprising of 5mm Clear Planibel G Low E glazing, 12mm Argon Gas filled spacer, and another layer of 5mm Clear Planibel Low E offers great thermal performance with R-values as high as 0.54 (in a timber frame). This double glazed louvre is ideal for use in colder climates, or any applications that require higher levels of thermal insulation.
Enhance energy efficiency and comfort with the IGLU® Double Glazed Louvre System
The Altair IGLU Double Glazed System maximises ventilation with wide openings and provides superior wind and water performance, while also offering improved energy efficiency and excellent thermal ratings, making it ideal for energy-efficient projects.
The IGLU Clip utilises the Breezway Stronghold® System, granting superior blade retention and compliance with Fall Prevention Standards. The stepped nature of the IGLU Blade allows for the internal glazing layer to be retained within the clip, while the outer glazing layer finishes flush with the clip. This allows for a completely flat aesthetic to the outside of the window.
Breezway Altair IGLU Blades do not have thermally compromising aluminium framing. Instead, the blades are capped top and bottom by rubber blade-to-blade seals, embedded into the IGU sealant, with a clean ceramic print running the perimeter of each blade to conceal the IGU spacer, while still drawing the eye through to the view outside.
IGLU System Brochure
Double Glazed Louvre System
View PDF.
IGLU Double Glazed Louvre System
The revolutionary Altair IGLU Double Glazed Louvre System is designed to allow maximum ventilation through the window opening while providing high thermal performance for residential or commercial designs.
IGLU
Technical
Size Specs
- Standard Heights only. Please refer to the Standard Height Chart in the Design Manual.
- Standard blade lengths stocked in 300mm, 500mm, 800mm and 1,127mm (ex-Australia).
- Custom blade lengths available for large projects (MOQ 500 pieces per unique blade type and length).
Technical Specs
- The 22mm IGLU Blade comprises of 5mm Clear Planibel G Low E Toughened Glass / 12mm Argon Gas / 5mm Clear Planibel G Low E Toughened Glass
- Altair Louvre Component System available for installation into compatible aluminium or timber framing systems.
- Range of customising options including automation, blade lengths, handle types, *colours and security.
IGLU Double Glazed Louvre in the APL Metro Series ThermalHEART® 56mm Window System (Manual Only):
- Average R-Value = 0.34
- Large size R-Value = 0.39
- Compliant with H1 Scheduling Method for Non-Housing Climate Zones 1-4.
- Compliant with H1 Calculation Method.
IGLU Double Glazed Louvre in the JMFNZ Timber Frame:
- Average R-Value = 0.48
- Large size R-Value = 0.54
- Compliant with H1 Scheduling Method in ALL Climate Zones.
- Compliant with H1 Calculation Method.
Other Performance Results:
Please note: Once the Stronghold System is installed, pins cannot be removed without specialised tools. Replacement pins required upon removal.
*IGLU Clips are available in black only. Please speak to Breezway for more information on customised colours.
IGLU System Product Testing
